| 气压零件 |
 |
 |
 |
 |
 |
12AWG(black)
Power cord (2.5m) |
Solenoid valve
signal cord (10m) |
8 AWG Power
cord(7m) |
10MM
Nylon line 1m |
Nylon line
4x6MM （25m） |
| JA-C2-0022 |
JA-C2-0023 |
JA-C2-0054 |
JA-C3-2044 |
JA-C3-2012/2015 |
 |
 |
 |
 |
 |
NylonLline
4x6MM(35m) |
22AWG(yellow) Power Cord (7m) |
60A Fuse box |
60A Fuse |
40A VIAIR Relay |
| JA-C3-2013 |
JA-C2-0068 |
JA-C2-0055 |
JA-C2-0056 |
JA-C2-0051 |
 |
 |
 |
 |
 |
| VIAIR 485C Piston |
VIAIR 485C AIR VALVE PLATE |
VIAIR 485C BACK CASE ASSEMBLY |
1/4 Solenoid Valve |
Solenoid Valve |
| JA-C2-0060 |
JA-C2-0062 |
JA-C2-0063 |
JA-C3-2019 |
JA-C2-0047 |
 |
 |
 |
 |
 |
| Solenoid Valve |
Solenoid Valve |
Solenoid Valve For OLD Type w/silver bottom |
3/8 24UNF Pressure Sensor w/O ring |
3/8 24UNF Pressure Sensor w/O ring*4 w/ bracket |
| JA-C2-0059 |
JA-C2-0066 |
JA-C2-0067 |
JA-C2-0050 |
JA-C2-0058 |
 |
 |
 |
 |
 |
| AFH-3 Pressure Sensor |
Pressure switch 150~175 PSI |
Mechanical Switch |
Electric Switch |
Safety Valve |
| JA-C7-0003 |
JA-C3-2017 |
JA-C3-2021 |
JA-C3-2022 |
JA-C5-0043 |
 |
 |
 |
 |
 |
| VIAIR 444C Check Valve |
VIAIR 485C Check Valve |
VIAIR 485C FILTER |
6MML 1/8outer pitch |
6MML 3/8outer pitch |
| JA-C5-0047 |
JA-C2-0061 |
JA-C2-0064 |
JA-C5-0010 |
JA-C5-0012 |
 |
 |
 |
 |
 |
6MM
L Shape Fitting |
6MM 1/8 outer pitch |
6MM 3-direction
fitting |
1/8PT 1/4 pitch
bushing |
Butterfly Valve |
| JA-C5-0016 |
JA-C5-0021 |
JA-C5-0028 |
JA-C5-0033 |
JA-C5-0037 |
 |
 |
 |
 |
 |
| 1/4*1/4 inner outer pitch |
1/4 inner outer
3-direction Fitting |
6MM 1/4outer Strength-Saving Adapter |
10MM 1/4outer Strength-Saving Adapter |
1/4*3/8 24UNFAdapter for pressure sensor |
| JA-C5-0041 |
JA-C5-0042 |
JA-C5-0044 |
JA-C5-0045 |
JA-C5-0049 |
 |
 |
 |
 |
 |
| 1/8*3/8 24UNFAdapter for pressure sensor |
3/8NPT inner pitch*1/4PT outer pitch |
Luxury RemoteControl (incl. wireset) |
Remote Control(Luxury) |
AFH Simple Remote Control |
| JA-C5-0050 |
JA-C5-0051 |
JA-C2-0016 |
JA-C2-0033 |
JA-C2-0045 |
 |
 |
 |
 |
 |
AFH-2 Remote Control+
ECU Board |
AFH-2 Remote Control+
Simple Remote Control+
ECU Board |
AFH-3 Remote Control + ECU Board |
APP Bluetooth
Receiver |
AFH Remote Battery |
| JA-C2-0044 |
JA-C6-1027 |
JA-C7-0001 |
JA-C2-0049 |
JA-C2-0057 |
 |
 |
 |
 |
 |
| 20L Air tank |
14L Stainless steel Air Tank |
12L Stainless steel Air Tank (60cm) |
VIAIR Compressor assembly (485C) |
AZ Air Hose |
| JA-C4-1001 |
JA-C4-1003 |
JA-C4-1004 |
JA-C6-1020 |
JA-C5-0039 |
 |
 |
 |
 |
|
| VIAIR 485C Air Hose |
Motor vibration-free
mounting Hardware |
Silencer 1/4PT |
Basic Dual Needle Gauge Assembly |
Deluxe Dual Needle Gauge Assembly |
| JA-C2-0065 |
JA-C3-2011 |
JA-C2-0048 |
JA-C6-1001 |
JA-C6-1002 |
 |
 |
 |
 |
 |
| Dual Needle Gauge |
Height sensor kit*1 |
Height sensor kit*2 |
AFH-2 Height sensor kit*4
(incl. wire set) |
HEIGHT SENSOR ACCESSORY |
| JA-C3-2023 |
JA-C3-2049 |
JA-C3-2045 |
JA-C3-2047 |
JA-C3-0050 |
 |
 |
 |
 |
 |
| Vibration-free Socket for Air Compressor |
AFH-3 Height Sensor Wire Set |
AFH-3 Height Sensor Kit*4(incl. wire set) |
ECU Board (AFH-3) |
Remote Control (NO ECU Board) |
| JA-C3-0051 |
JA-C7-0004 |
JA-C7-0005 |
JA-C7-0006 |
JA-C7-0007 |
 |
 |
 |
 |
 |
| Basic Management Assembly |
Basic Management Assembly NO COMPRESSOR & TANK |
NEW Deluxe ECM Assembly |
NEW Deluxe Management Assembly |
Super Pro. ECM Assembly |
| JA-C6-1004 |
JA-C6-1023 |
JA-C6-1022 |
JA-C6-1021 |
JA-C6-1018 |
 |
 |
 |
 |
 |
| Super Pro. Management Assembly |
Gold ECM Assembly
(incl. height sensor&APP Bluetooth Receiver)
|
Gold Management Assembly |
Super Pro. Solenoid (AFH-2) |
Gold Solenoid (AFH-2) |
| JA-C6-1007 |
JA-C6-1019 |
JA-C6-1008 |
JA-C6-1024 |
JA-C6-1025 |
 |
 |
|
|
|
| ECU Board (AFH-2) |
AFH-3 Solenoid Valve Coil |
|
|
|
| JA-C6-1028 |
JA-C7-0002 |
|
|
|
